Fetal Doppler JSL-T501

Fetal Doppler JSL-T501

Fetal Doppler JSL-T501 is a portable fetal heart rate monitoring device designed to detect and listen to fetal heart sounds during pregnancy. It uses Doppler ultrasound technology with a sensitive probe and provides a digital fetal heart rate reading on the LCD display.

The compact handheld design makes the JSL-T501 Fetal Doppler convenient for use in clinics, maternity care settings, and professional prenatal monitoring. It features clear audio output through the built-in speaker and also supports headphone connection for more private listening.

The device operates on 2 × AA batteries, making it convenient for portable use without requiring a continuous power connection.

Key Features

• Portable Fetal Doppler
• Model: JSL-T501
• Doppler Ultrasound Technology
• High-Sensitivity Probe
• Digital LCD Display
• Fetal Heart Rate (FHR) Display
• Clear Built-In Speaker
• 3.5mm Headphone Support
• Adjustable Volume
• Portable Battery-Powered Design
• Simple Button Operation
• Lightweight and Easy to Carry

Benefits

The JSL-T501 Fetal Doppler provides a convenient way for trained healthcare professionals to monitor and listen to fetal heart activity.

Ideal for:

• Prenatal monitoring
• Maternity clinics
• Obstetric care
• Hospitals
• Midwifery practice
• Medical training and education
• Fetal heart sound observation

Technical Specifications

• Product Name: Fetal Doppler
• Model: JSL-T501
• Product Type: Portable Fetal Heart Rate Monitor
• Technology: Doppler Ultrasound
• Ultrasound Frequency: Approximately 2.5 MHz
• Fetal Heart Rate Range: Approximately 50–240 BPM
• Display: Digital LCD / TFT Display depending on version
• Audio Output: Built-In Speaker
• Headphone Output: 3.5mm Jack
• Probe: Wired Handheld Doppler Probe
• Power: 2 × AA Batteries
• Dimensions: Approximately 140 × 68 × 28 mm
• Weight: Approximately 150g including probe, excluding batteries

How To Use Fetal Doppler

1. Insert 2 × AA batteries according to the correct polarity.
2. Connect or check the Doppler probe.
3. Apply a suitable amount of ultrasound gel to the probe or abdomen as recommended.
4. Turn on the device.
5. Place the probe gently on the appropriate area of the abdomen.
6. Slowly move the probe until a clear fetal heart sound is detected.
7. Read the fetal heart rate shown on the digital display.
8. Adjust the volume or use compatible headphones when required.
9. Clean the probe after use according to the manufacturer’s instructions.

Package Includes

• 1 × Fetal Doppler JSL-T501
• 1 × Fetal Doppler Probe
• 1 × User Manual
• 2 × AA Batteries

Care & Storage Instructions

• Keep the main device clean and dry.
• Do not immerse the electronic unit in water.
• Clean the probe according to the manufacturer’s instructions.
• Avoid dropping or applying excessive force to the probe.
• Keep the device away from extreme heat and direct sunlight.
• Remove batteries if the device will not be used for an extended period.
• Store in a clean and dry place.

Important Safety Information

The Fetal Doppler is intended as a fetal heart sound monitoring aid and should be used according to the manufacturer’s instructions and appropriate clinical practice. It should not be used as a substitute for professional prenatal examination, ultrasound, or medical diagnosis.

Failure to detect a fetal heartbeat does not necessarily indicate a medical problem, and an audible heartbeat does not by itself confirm fetal well-being. If there are concerns about fetal movement, pregnancy symptoms, or fetal health, seek assessment from a qualified healthcare professional.
